Overview
This section contains the removal and replacement procedures for selected parts of the
printer according to the Field Replaceable Units (Service Parts) Parts List. In general,
replacement procedures are not given because re-installing a part is simply a reversal
of the disassembly. Replacement procedures are included where this is not the case
and special steps are required. Replacement notes are included when they can help
ease or shorten the reassembly process.
Standard Orientation of the System
When needed, the orientation of the system is called out in the procedure for locating
printer parts. Refer to the system orientation graphic for locating the right, left, front
and back sides of the printer.
