AnywhereUSB® Plus User Guide
482
Configure packet capture for the network analyzer
To use the network analyzer, you must create one or more packet capture configuration.
Required configuration items
n
The interface used by this packet capture configuration.
Additional configuration items
n
The filter expression for this packet capture configuration.
n
Schedule the analyzer to run based on a specified event or at a particular time:
l
The events or time that will trigger the analyzer to run, using this capture configuration.
l
The amount of time that the analyzer session will run.
l
The frequency with which captured events will be saved.
To configure a packet capture configuration:
ÉWebUI
1. Log into the AnywhereUSB Plus WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Analyzer.
4. For Add Capture settings, type a name for the capture filter and click g.
The new capture filter configuration is displayed.
