Configure the AnywhereUSB Manager from the command line hidden hub add

AnywhereUSB® Plus User Guide

760

hidden hub add

Purpose

Hide a Hub by adding it to the hidden Hubs list.

Note For information on hiding Hubs in the AnywhereUSBManager, see Hide an individual Hub and

Hide all unauthorized Hubs.

Syntax

>awusbmanager hidden hub add,<address>[:port]

The [address] is the address of the Hub that you want to hide

The <port> is the TCPport number for the Hub you want to hide. This is required if the TCP port

number is not the default (18574).

Examples

Run the hidden hub add command to add a Hub to the hidden Hub list.

Use the default port of 18574:

>awusbmanager hidden hub add,10.10.10.34

Change the TCPport number:

>awusbmanager hidden hub add,10.10.10.56:5600

You can then run the hidden hub list command to verify that the Hubs were added to the list of

hidden Hubs.

10.10.10.34:18574

10.10.10.56:5600
