Routing Virtual Router Redundancy Protocol (VRRP)

AnywhereUSB® Plus User Guide

546

Configure device one (master device)

ÉWebUI

Task 1: Configure VRRP on device one

1. Log into the AnywhereUSB Plus WebUI as a user with full Admin access rights.

2. On the menu, click System. Under Configuration, click Device Configuration.

The Configuration window is displayed.

3. Click Network > VRRP.

4. For Add VRRP instance, type a name for the VRRP instance and click g.

The new VRRP instance configuration is displayed.
