Diagnostics Analyze network traffic
AnywhereUSB® Plus User Guide
495
Checksum : 0xc740
Urgent Pointer : 0
TCP Data
00 00 00 00 00 00 ......
>
where capture_filter is the name of a packet capture configuration. See Configure packet
capture for the network analyzer for more information.
To determine available packet capture configurations, use the ?:
> show anaylzer name ?
name: Name of the capture filter to use.
Format:
test_capture
capture_ping
> show anaylzer name
Save captured data traffic to a file
Data traffic is captured to RAM and when the device reboots, the data is lost. To retain the captured
data, first save the data to a file and then upload the file to a PC.
To save captured traffic data to a file, use the analyzer save command:
Command line
1. Log into the AnywhereUSB Plus command line as a user with Admin access.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. Type the following at the Admin CLI prompt:
> analyzer save filename filename name capture_filter
>
where:
n
filename is the name of the file that the captured data will be saved to.
Determine filenames already in use:
Use the tab autocomplete feature to determine filenames that are currently in use:
> analyzer save name <tab>
test1_analyzer_capture test2_analyzer_capture
> analyzer save name
n
capture_filter is the name of a packet capture configuration. See Configure packet
capture for the network analyzer for more information.
To determine available packet capture configurations, use the ?:
