Routing IP routing
AnywhereUSB® Plus User Guide
517
Configure a routing policy
Required configuration items
n
The packet matching parameters. It can any combination of the following:
l
Source interface.
l
Source address. This can be a firewall zone, an interface, a single IPv4/IPv6 address or
network, or a MACaddress.
l
Destination address. This can be a firewall zone, an interface, a single IPv4/IPv6 address or
network, or a domain.
l
Protocol. This can be any, tcp, udp or icmp.
l
Source port. This is only used if the protocol is set to tcp or udp.
l
Destination port. This is only used if protocol is set to tcp or udp.
n
The network interface used to reach the destination.
Additional configuration items
n
A label for the routing policy.
n
Whether packets that match this policy should be dropped when the gateway interface is
disconnected, rather than forwarded through other interfaces.
To configure a routing policy:
ÉWebUI
1. Log into the AnywhereUSB Plus WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Routes > Policy-based routing.
4. Click the gto add a new route policy.
The new route policy page is displayed:
New route policies are enabled by default. To disable, click to toggle Enable to off.
5. (Optional) For Label, type a label that will be used to identify this route policy.
