Configuration
2026419-033E CIC Pro™ 6-55
Screen calibration
CAUTION
When using a video splitter with the CIC Pro center, screen
calibration may be possible with only one of the monitors connected
to the splitter. This is because changing calibration for one monitor
will effect the calibration of all other monitors connected to that
same splitter.
When using monitors connected to a splitter, only the last monitor
calibrated will have proper calibration. Manual measurements
should be made from that monitor only.
NOTE
Screen calibration should be performed every time a monitor is installed or
serviced.
NOTE
If two displays are connected to the CIC Pro center, complete the screen
calibration on the primary display first, then the secondary display.
Calibrating the display screen adjusts the waveform gain and sweep speed to ensure
the displayed sweep speed is accurate.
A flexible clear plastic ruler calibrated in inches and centimeters is recommended for
this procedure.
1. From the multi-patient viewer, click Setup CIC.
2. Log on to Setup CIC with service access on page 4-5.
3. On the CIC Setup screen, click Display Configuration.
