Field replaceable units (FRUs)
2026419-033E CIC Pro™ 9-21
4. Remove the AC power cable that connects to the power supply.
5. Remove the four screws that connect the power supply to the chassis (retain the
screws).
6. Replace the power supply.
7. Reverse steps to re-assemble.
8. Re-assemble the cover on page 9-24.
9. Perform the following checkout procedures:
Perform Ground continuity test on page 10-6.
Perform Ground (earth) wire leakage current test on page 10-7.
Perform Enclosure leakage current test on page 10-8.
Check internal hardware temperature and voltage status on page 7-12.
Verify that the power LED is on after the unit is powered up.
Replacing the fan
CAUTION
NETWORK DEVICE TIME SYNCHRONIZATION — When
adding a new device (e.g., CIC Pro center) to the CARESCAPE
Network, the existing devices on the CARESCAPE Network will
synchronize to the new device’s time. To prevent potential time
synchronization issues, you should set the new device’s time to be as
close as possible to the time (within a few seconds) used by the
existing GE devices on the CARESCAPE Network.
NOTE
There are two internal fans. Either can be replaced independently.
1. Prepare the unit for disassembly on page 9-12.
2. Remove the cover on page 9-13.
3. Remove the two fan cables from the CPU PCB.
4. Remove the two screws that connect the fan to the back of the chassis (retain the
screws).
5. Replace the fan.
6. Reverse steps to re-assemble.
7. Re-assemble the cover on page 9-24.
8. Perform the following checkout procedures:
Perform Ground continuity test on page 10-6.
Perform Ground (earth) wire leakage current test on page 10-7.
Perform Enclosure leakage current test on page 10-8.
Check internal hardware temperature and voltage status on page 7-12.
