5-18 CIC Pro™ 2026419-033E
Installation
2. Remove the old spool and install a new paper roll so it unrolls from the bottom.
3. Close the door. Make sure the paper protrudes from the opening.
4. Test the writer by initiating a graph strip.
5. Remove the test graph by tearing downward.
Plug in the power cable to the CIC Pro center
WARNING
Ample access for AC power cord disconnect (from the wall outlet,
or from the back of the unit) is vital to provide positive AC power
disconnection for service or in the event of emergency.
1. Insert the power cable into the power outlet on the CIC Pro center.
2. Tighten the cable clamp screw to secure the clamp to the chassis.
3. Insert the power cable into a UPS. See Un-interruptible power supply (UPS) on
page 5-7.
