8-16 CIC Pro™ 2026419-033E
Troubleshooting
4. Click Submit.
5. If the waveforms are one of the colors listed in the following table, contact
Technical Support.
Require age selection for admit
For instructions on forcing age selection when admitting a pediatric patient, refer to
Configure force age setting, if applicable on page 6-23.
Licensing issues
If you are installing a new CIC Pro center, see Activate licenses (automatically) using
a USB memory stick with the CIC Pro center on page 6-10. If you are activating
licenses at a later date, perform one of the following procedures:
Activate licenses (automatically) via a service PC on page 8-16.
Activate licenses (manually) via the Activation Code Summary Sheet on page 8-
18.
Activate licenses (automatically) via a service PC
Use this procedure when the license activation codes are retrieved from a service PC
via a USB memory stick, CD, or the service PC’s hard drive.
Option Function
Enable (TTX only) Display only telemetry indicators.
Enable (all) Display all waveform indicators.
Disable Remove all waveform indicators.
Waveform color Interpretation
Yellow Missing data from the transmitter.
Dark green Missing data from RX network.
Magenta Missing data from the Receiver subsystem (Rack).
Orange Missing data from Hardware Manager.
Light gray Invalid telemetry data.
Cyan Missing data from network.
White Waveform re-sync.
Blue Waveform buffer empty.
Red Waveform buffer overflow.
Dark gray Unknown error.
