Field replaceable units (FRUs)
2026419-033E CIC Pro™ 9-9
NOTE
GE recommends that you assemble the devices using the new hardware (screws,
washers, etc.) provided in the FRU. Some hardware (e.g., screws with a thread
locking coating) are not intended for re-use.
NOTE
During disassembly, note the positions of wires, cables, and different sized
screws; labeling them if necessary to ensure they are replaced correctly.
Use the following table as a checklist for replacing FRUs for the CIC Pro center:
Desktop assembly
Refer to Replacement procedures on page 9-8 for a description of the parts referenced
in the following diagram.
ID on
assembly
diagrams
1
Part number Description Replacement and checkout procedures
1 2039793-002 FRU MP100 CPU PCB Replacing the CPU PCB (mother board) on page 9-14.
2 2039793-003 FRU MP100 FAN Replacing the fan on page 9-21.
3 2039793-004 FRU MP100 DUAL SPEAKERS Replacing the dual speakers on page 9-22.
4 2039793-005 FRU MP100 POWER SUPPLY Replacing the power supply on page 9-20.
5 2039793-006 FRU MP100 SATA DRIVE CABLES Replacing the SATA drive cables on page 9-19.
6 2039793-009 FRU MP100 120G SATA HD Replacing the hard drive on page 9-17.
7 2039793-010 FRU MP100 8G SATA FLASH DRIVE Replacing the flash drive on page 9-18.
8 2039793-008 FRU MP100 FRONT BEZEL (Desktop
unit only)
Replacing the front bezel on page 9-23.
not pictured 2039793-007 FRU MP100 HARDWARE Since this FRU contains screws, etc., no specific procedure
is provided.
not pictured 2020183-006 FRU CIC PRO 4A SB FUSES Replacing the fuse on page 9-22.
1
These numbers are shown on the following desktop and rack-mount assemblies.
