9-24 CIC Pro™ 2026419-033E
Field replaceable units (FRUs)
8. Re-assemble the cover on page 9-24.
9. Perform the following checkout procedures:
Perform Ground continuity test on page 10-6.
Perform Ground (earth) wire leakage current test on page 10-7.
Perform Enclosure leakage current test on page 10-8.
Perform general visual inspection. See Visual inspection on page 10-3.
Inspect fans and power supply.
Inspect connectors.
Inspect cable insulation.
Clean external surfaces. See External surfaces on page 10-4.
Clean internal components. See Internal components on page 10-5.
Clean fans.
Clean filters.
Check access to all other care units on page 7-7.
Verify that the power LED is on after the unit is powered up.
Re-assemble the cover
WARNING
SHOCK HAZARD —Whenever the cover is removed, you can
disrupt internal components and potentially disrupt proper power or
ground connections. The potential for electric shock exists. When
the cover is replaced, perform Electrical safety tests on page 10-6
and FRU checkout procedures on page 7-10.
Re-assemble the cover on the desktop
1. Slide the cover over the chassis.
2. Replace the eight screws that connect the cover to the sides of the chassis.
3. If you did replace any parts after opening up the cover, you will have to perform
Electrical safety tests on page 10-6 and FRU checkout procedures on page 7-10.
Re-assemble the cover on the rack-mount
1. Slide the cover into the chassis.
2. Replace the four screws that connect the cover to the back of the chassis.
3. If you did replace any parts after opening up the cover, you will have to perform
Electrical safety tests on page 10-6 and FRU checkout procedures on page 7-10.
