5-10 CIC Pro™ 2026419-033E
Installation
CAUTION
POWER REQUIREMENTS — Before connecting the device to the
power line, check that the voltage and frequency ratings of the
power line are the same as those indicated on the unit’s label. If this
is not the case, do not connect the system to the power line until you
adjust the unit to match the power source.
In the USA, if the installation of the equipment will use 240V rather
than 120V, the source must be a center-tapped, single-phase circuit.
This equipment is suitable for connection to public mains as defined
in CISPR 11.
CAUTION
All external cabling used with the CIC Pro center must be routed so
it does not interfere with access to, or operation of, the CIC Pro
center. Install cabling to guard against tripping and accidental cable
disconnection.
CAUTION
Do not apply power until all equipment is installed and ready for
use.
CAUTION
This assembly is static sensitive and should be handled using
precautions to prevent electrostatic discharge damage.
Installation process checklist
Complete the following tasks in the order presented:
Mount the equipment on page 5-11.
Connect the cables and peripheral devices on page 5-12.
Connect the keyboard and mouse on page 5-12.
Connect the external speakers on page 5-12.
Connect the display(s) on page 5-13.
Install optional accessories on page 5-16:
Install laser printers on page 5-16.
Connect the digital writer on page 5-17.
Plug in the power cable to the CIC Pro center on page 5-18.
Turn on the power on page 5-19.
