Installation
2026419-033E CIC Pro™ 5-13
NOTE
External speakers are connected during normal operation. An alert message
displays when no external speaker connection is present. This is true even if
the CIC Pro center is used as a mirrored CIC Pro center and its audible alarm
volume is set to OFF.
All clinical setting values must be received from the GE Clinical Application
Specialist (CAS) or from the nursing director of the care unit. Consult with
your CAS or hospital staff about the use of the various alarms in your
environment and the configuration of the alarm audio settings.
No extenders are supported for the speaker. For more information, see
Restrictions on page 5-11.
1. Connect the external speaker cable into the speaker port on the CIC Pro
center.
2. Tighten the cable clamp screw to secure the clamp to the chassis.
Connect the display(s)
Valid display configurations
The primary display video connection supports DVI-I analog/digital connections.
Analog VGA monitors require a DVI to VGA adapter. See Accessories on page 9-6.
NOTE
The primary or secondary display can be a non-touchscreen or touchscreen
display.
The part numbers for the supported digital video cables are listed in
Accessories on page 9-6.
Connect the primary display
Complete the applicable steps in the following table to connect up to two displays to
the CIC Pro center.
Primary Secondary
Single Display system DVI-D or VGA N/A
Dual Display system
(Requires license)
DVI-D or VGA DVI-D only
