MFG-2000 Series User Manual
102
Pulse Channel
As the MFG-2000 Serise are multi channel models, the desired
output channel must first be selected before assigning the operation
for that channel.
Setup Pulse waveform
1. Press the Pulse or Pulse/RF
key to Select Pulse.
2. The selected channel will be visible while the
deselected channel will be dimmed.
In the screen shot below, Pulse is selected.
For 21XX model for 22XX model
The display location for Pulse channel are different in
the 21XX and 22XX series device. We take the 22XX
illustration as example in the following context.
