GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
345
Example
SOUR1:BURS:TRIG:SLOP NEG
Sets the trigger slope to negative.
Query Syntax
SOURce[1|2|3|3RF]:BURSt:TRIGger:SLOPe?
Return Parameter
POS
rising edge
NEG
falling edge
Example
SOUR1:BURS:TRIG:SLOP ?
NEG
The trigger slope is negative.
SOURce[1|2|3]:BURSt:GATE:POLarity
Source Specific
Command
Description
In gated mode, the function generator will output
a waveform continuously while the external
trigger receives logically true signal from the
Trigger INPUT terminal. Normally a signal is
logically true when it is high. The logical level can
be inverted so that a low signal is considered true.
Syntax
SOURce[1|2|3]:BURSt:GATE:POLarity
{NORMal|INVertes}
Parameter
NORMal
Logically high
INVertes
Logically low
Example
SOUR1:BURS:GATE:POL INV
Sets the state to logically low (inverted).
Query Syntax
SOURce[1|2|3]:BURSt:GATE:POLarity?
Return Parameter
NORM
Normal(High) logical level
INV
Inverted (low) logical level
Example
SOUR1:BURS:GATE:POL?
INV
The true state is inverted(logically low).
