GW Instek MFG-2000 Series User Manual

QUICK REFERENCE
51

     
     
     
    
   
     
  

     

     
     
     
2. Press Start (F1), 0 +
Enter (F5), Return.

Ea

3. Press Length (F2), 1 +
0 + 0, Enter (F5),
Return.

gh


E 
ARB– Output N Cycle
Example: ARB Mode, Output N Cycle, Start 0, Length 1000, N
Cycle 10.
Output:

     
     
     
    
   
     
  

     

     
     
     
1. Press ARB,
Output(F6).

O
2. Press Start(F1),
0+Enter (F5),
Return(F6).

Ea

3. Press Length(F5),
1+0+0, Enter(F5),
Return(F6).

gh


E 
4. Press N Cycle (F4).

 d
5. Press Cycle(F1), 1+0.



6. Press Trigger(F5) to
trigger the output
once.
gg
