GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
294
Amplitude Modulation (AM) Commands
AM Overview
To successfully create an AM waveform, the following commands
must be executed in order.
Enable AM
Modulation
Configure Carrier
Select
Modulation
Source
Select Shape
Set Modulating
Frequency
Set Modulation
Depth
1. Turn on AM modulation using the
SOURce[1|2|3RF]:AM:STAT ON command
2. Use the APPLy command to select a carrier
waveform. Alternatively the equivalent FUNC,
FREQ, AMPl, and DCOffs commands can be
used to create a carrier waveform with a
designated frequency, amplitude and offset.
3. Select an internal or external modulation source
using the SOURce[1|2|3RF]: AM:SOUR
command.
4. Use the SOURce[1|2|3RF]: AM:INT:FUNC
command to select a sine, square, upramp,
dnramp or triangle modulating waveshape. For
internal sources only.
5. Set the modulating frequency using the
SOURce[1|2|3RF]: AM:INT:FREQ command.
For internal sources only.
6. Set the modulation depth using the
SOURce[1|2|3RF]: AM:DEPT command.
