GW Instek MFG-2000 Series User Manual

QUICK REFERENCE
43
9. Press MOD,
PWM(F6),
Source(F1),INT(F1)

 

10. Press the Output
key.
SUM Modulation
Example: SUM modulation. 100Hz modulating square wave, 1kHz
sinusoidal carrier wave, 50% SUM amplitude, internal source.
Output:

     
     
     
    
   
     
  

     

     
     
     
1. Press the MOD key,
then SUM (F5).


2. Press Waveform, and
select Sine (F1).


Input: N/A
3. Press Freq/Rate
followed by 1 + kHz
(F5).

kz
Q
4. Press the MOD key,
SUM (F5), Shape (F4),
Square (F2).

 ha
qa
5. Press the MOD key
and select SUM (F5),
SUM Freq (F3).

 q
6. Press 1 + 0 + 0 + Hz
(F2).


z

7. Press the MOD key
and select SUM (F5),
SUM Ampl (F2).

 
