GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
309
Note
For FSK, the modulating waveform is a square
wave with a duty cycle of 50%.
Syntax
SOURce[1|2|3|3RF]:FSKey:FREQuency
{<frequency>|MINimum|MAXimum}
Parameter
<frequency>
1 μHz to Max Frequency
Example
SOUR1:FSK:FREQ +1.0000E+02
Sets the FSK hop frequency to to 100Hz.
Query Syntax
SOURce[1|2|3|3RF]:FSKey:FREQuency?
[MINimum|MAXimum]
Return Parameter
<NR3>
Returns the frequency in
Hz.
Example
SOUR1:FSK:FREQ?
+1.0000000000000E+02
Returns the frequency to 100Hz.
SOURce[1|2|3|3RF]:FSKey:INTernal:RATE
Source Specific
Command
Description
Sets or queries the FSK rate for internal sources
only.
Note
External sources will ignore this command.
Syntax
SOURce[1|2|3|3RF]:FSKey:INTernal:RATE {<rate in
Hz> |MINimum|MAXimum}
Parameter
<rate in Hz>
2 mHz~100 kHz
Example
SOUR1:FSK:INT:RATE MAX
Sets the rate to the maximum (1MHz).
Query Syntax
SOURce[1|2|3|3RF]:FSKey:INTernal:RATE?
[MINimum|MAXimum]
Return Parameter
<NR3>
Returns the FSK rate in
Hz.
Example
SOUR1:FSK:INT:RATE? MAX
+1.000000000E+05
Returns the maximum FSK rate allowed.
