GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
348
Frequency,
amplitude and
offset
Load Waveform
Data
Set Waveform
Rate
2. Use the APPLy command to select
frequency, amplitude and DC offset.
Alternatively, the FUNC, FREQ, AMPl, and
DCOffs commands can be used.
3. Waveform data (1 to 16384 points per
waveform) can be downloaded into volatile
memory using the DATA:DAC command.
Binary integer or decimal integer values in
the range of ± 8191can be used.
4. The waveform rate is the product of the
number of points in the waveform and the
waveform frequency.
Rate = Hz × # points
Range:
Rate:
1μHz ~ 200MHz
Frequency:
1μHz ~ 100MHz
# points:
1~16384
SOURce[1|2|3]:FUNCtion USER
Source Specific
Command
Description
Use the SOURce[1|2|3]:FUNCtion USER
command to output the arbitrary waveform
currently selected in memory. The waveform is
output with the current frequency, amplitude and
offset settings.
Syntax
SOURce[1|2|3|3RF]:FUNCtion USER
Example
SOUR1:FUNC USER
Selects and outputs the current waveform in
memory.
