GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
297
SOURce[1|2|3RF]:AM:INTernal:FREQuency
Source Specific
Command
Description
Sets the frequency of the internal modulating
waveform only. The default frequency is 100Hz.
Syntax
SOURce[1|2|3RF]:AM:INTernal:FREQuency
{<frequency>|MINimum|MAXimum}
Parameter
<frequency>
2 mHz~ 20 kHz
Example
SOUR1:AM:INT:FREQ +1.0000E+02
Sets the modulating frequency to 100Hz.
Query Syntax
SOURce[1|2|3RF]:AM:INTernal:FREQuency?
[MINimum|MAXimum]
Return Parameter
<NR3>
Returns the frequency in
Hz.
Example
SOUR1:AM:INT:FREQ?
+1.0000000E+02
Returns the frequency to 100Hz.
SOURce[1|2|3RF]:AM:DEPTh
Source Specific
Command
Description
Sets or queries the modulation depth for internal
sources only. The default is 100%.
Note
The function generator will not output more than
±5V, regardless of the modulation depth.
The modulation depth of an external source is
controlled using the ±5V MOD INPUT terminal on
the rear panel, and not the
SOURce[1|2|3RF]:AM:DEPTh command.
Syntax
SOURce[1|2|3RF]:AM:DEPTh {<depth in percent>
|MINimum|MAXimum}
Parameter
<depth in percent>
0~120%
Example
SOUR1:AM:DEPT 50
Sets the modulation depth to 50%.
