MFG-2000 Series User Ma
nual
176
Center Frequency and Span
A center frequency and spa
n can be set to dete
rmine the
upper and
lower sweep limits (start
/stop).
Panel
Operation
1.
Pre
ss the SWEEP
key.
2.
Pre
ss F6 (More).
3.
Pre
ss F1 (Span)
or F2 (Center)
to select the span or cen
ter.
a
~
4.
The
Span or Center para
meters will become
hightlighted in the
waveform display area
.
Span
C
enter
175
177
