GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
277
Sets frequency to 2kHz and sets the amplitude and
offset to the maximum.
SOURce[1|2|3|3RF]:APPLy:RAMP
Source Specific
Command
Description
Outputs a ramp wave from the selected channel
when the command has executed. Frequency,
amplitude and offset can also be set. The
symmetry is set to 100%.
Syntax
SOURce[1|2|3|3RF]:APPLy:RAMP [<frequency>
[,<amplitude> [,<offset>] ]]
Parameter
<frequency>
1μHz~1MHz
<amplitude>
1mVpp~10Vpp (50Ω)
<offset>
±5 Vpk ac +dc (50Ω)
Example
SOUR1:APPL:RAMP 2KHZ,MAX,MAX
Sets frequency to 2kHz and sets the amplitude and
offset to the maximum.
SOURce[1|2|3|3RF]:APPLy:PULSe
Source Specific
Command
Description
Outputs a pulse waveform from the selected
channel when the command has executed.
Frequency, amplitude and offset can also be set.
Note
The PW settings from the
SOURce[1|2|3|3RF]:PULS: WIDT command are
preserved. Edge and pulse width may be adjusted
to supported levels.
Repetition rates will be approximated from the
frequency. For accurate repetition rates, the period
should be adjusted using the
SOURce[1|2|3|3RF]:PULS:PER command
Syntax
SOUR[1|2|3|3RF|pulse]:APPLy:PULSe [<frequency>
[,<amplitude> [,<offset>] ]]
Parameter
<frequency>
500μHz~25MHz
