GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
202
System and Settings
There are a number of miscellaneous settings and firmware settings
that can be configured.
Viewing and Updating the Firmware
Panel Opearon
1. Press the UTIL key.

2. Press F3 (Cal.).
a.

3. Press F2 (Software).
a

View Version
4. Press F1 (Version) to view the
firmware version.
V

The version information will be shown on
screen:
Instrument, Version, FPGA Version, Bootloader
Version
Update Firmware
5. To update the firmware,
insert a USB flash drive with
a firmware file in the USB
host drive. Press F2
(Upgrade).
gad

6. Press F1 (Select) to select the
corresponding CPU file.
Note
FPGA file must be located in the USB root directory. To
update, do select the the CPU file rather than the
FPGA file.
