GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
158
PSK Rate
The PSK modulation time determines whether the carrier phase or
modulation phase is output.
Panel Operation
1. Select MOD.

2. Press F3 (PSK).
K

3. Press F3 (PSK Rate).
Ka

4. The PSK rate parameter will become
highlighted in the parameter window.
5. Use the arrow keys and scroll
wheel or number pad to enter
the PSK rate.

/


 



6. Press F1~F4 to select the
frequency units.
z

~
kz

Range
PSK modulaton time
2mHz~1MHz
Default
10Hz
