MFG-2000 Series User Manual

360

SOURce[1|2]:TRACk

Instrument

Command

Description

Turns tracking on or off.

Syntax

SOURce[1|2]:TRACk {ON|OFF|INVerted}

Parameter/

Return Parameter

OFF

INVerted

Example

SOURce1:TRACk ON

Turns tracking on. Channel 2 will “track” the

changes of channel 1.

Query Syntax

SOURce[1|2]:TRACk?

Example

SOURce1:TRACk?

Channel tracking is turned on.
