MFG-2000 Series User Manual

254

Web Browser Control Interface

The MFG-2000 also has a browser-based interface to remotely

control the unit over a network.

Overview

Welcome Page

The Welcome Page is the home page for the

browser control interface. This page lists

instrument information and the LAN

configuration. It also has links to the Browser

Web Control and the View & Modify

Configuration pages.
