GW Instek MFG-2000 Series User Manual

QUICK REFERENCE
41
10. Press Waveform and
select Sine (F1).


PSK Modulation
Example: PSK modulation. 50% phase deviation. 1kHz sine carrier
wave. 10Hz PSK rate. Internal source.
Output

     
     
     
    
   
     
  

     

     
     
     
1. Press MOD and select
PSK (F6).

K
2. Press Waveform and
select Sine(F1).


Input: N/A
3. Press the Freq/Rate
key, followed by 1 +
kHz (F5).

kz
Q
4. Press the MOD key,
select PSK (F6), PSK
Rate (F3).

K Ka
5. Press 1 + 0 + Hz (F2)


z
6. Press the MOD key,
select PSK (F6), PSK
Phase (F2).

K Kha
7. Press 5+ 0 + %(F3)
8. Press MOD, PSK(F6),
Source (F1), INT (F1)

K 

