SOURce[1|2]:BURSt:OUTPut:TRIGger:SLOPe
Source Specific
Command
Description
Sets or queries the trigger edge of the trigger
output signal. The signal is output from the trigger
out terminal on the rear panel. The default trigger
output slope is positive.
Note
The trigger output signal on the rear panel
depends on the burst trigger source or mode:
Immediate
50% duty cycle square wave is
output at the start of each burst.
External
Trigger output disabled.
Gated mode
Trigger output disabled.
Manual
A >1 ms pulse is output at the
start of each burst.
Syntax
SOURce[1|2|]:BURSt:OUTPut:TRIGger:SLOPe
{POSitive|NEGative}
Parameter
POSitive
Rising edge.
NEGative
Falling edge.
Example
SOUR1:BURS:OUTP:TRIG:SLOP POS
Sets the trigger output signal slope to positive
(rising edge).
Query Syntax
SOURce[1|2]:BURSt:OUTPut:TRIGger:SLOPe?
Return Parameter
POS
Rising edge.
NEG
Falling edge.
Example
SOUR1:BURS:OUTP:TRIG:SLOP?
POS
The trigger output signal slope to positive.
