GW Instek MFG-2000 Series User Manual

MODULATION
193
Burst Trigger Output
The Trig Out terminal on the rear panel can be used for burst or
sweep modes to output a rising edge TTL compatible trigger signal.
By default the trigger signal is rising edge. The trigger signal is
output at the start of each burst.
Panel Operation
1. Press the Burst key.

2. Press F1 (N Cycle).


3. Press F5 (TRIG setup).


4. Press F5 (TRIG out).


5. Press F3 (ON/OFF) to toggle
Trigger out ON/OFF.
OO

6. Select F1 (Rise) or F2 (Fall)
edge trigger.


~
a

Note
When the internal or external trigger is selected, the
trigger output signal will be at either a TTL low/high
level and will toggle when the specifed number of
waveform cycles completed.
When the manual trigger is selected, the trigger
output turns on at the trigger soft-key be pressed.
When the manual trigger is selected, the function
generator automatically disables the trigger output.
When using a manual trigger, the function generator
outputs a pulse wave (>1us) from the Trig Out
terminal.
