GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
342
SOURce[1|2|3]:BURSt:PHASe
Source Specific
Command
Description
Sets or queries the starting phase for the burst. The
default phase is 0 degrees. At 0 degrees, sine
square and ramp waveforms are at 0 volts.
In gated burst mode, waveforms are continuously
output (burst) when the Trig signal is true. The
voltage level at the starting phase is used to
determine the voltage level of the signal in-
between bursts.
Note
The phase command is not used with pulse
waveforms.
Syntax
SOURce[1|2|3]:BURSt:PHASe
{<angle>|MINimum|MAXimum}
Parameter
<angle>
-360 ~ 360 degrees
Example
SOUR1:BURS:PHAS MAX
Sets the phase to 360 degrees.
Query Syntax
SOURce[1|2|3]:BURSt:PHASe? [MINimum|MAXimum]
Return Parameter
<NR3>
Returns the phase angle in degrees.
Example
SOUR1:BURS:PHAS?
+3.600E+02
The burst phase is 360 degrees.
SOURce[1|2|3]:BURSt:TRIGger:SOURce
Source Specific
Command
Description
Sets or queries the trigger source for triggered
burst mode. In trigged burst mode, a waveform
burst is output each time a trigger signal is
received and the number of cycles is determined
by the burst count.
There are three trigger sources for triggered burst
mode:
