GW Instek MFG-2000 Series User Manual

SECONDARY SYSTEM FUNCTION SETTINGS
195
Save and Recall
The MFG-2000 has non-volatile memory to store instrument state
and ARB data. There are 10 memory files numbered 0~9. Each
memory file can either store arbitrary waveform data (ARB),
settings or both. When data (ARB or Setting data) is stored in a
memory file, the data will be shown in red. If a file has no data, it
will be shown in blue.
Save/Recall
Properties
ARB
 Rate
 Frequency
 Length
 Display horizontal
 Display vertical
 Output Start
 Output length
Setting
 Functions
 Waveform
 Frequency
 Pulse Width
 Edge time
 Square wave Duty
 Ramp Symmetry
 Amplitude
 Amplitude unit
 Offset
 Modulation type
 Beep setting
 Impedance
 Main output
 Sweep
 Source
 Type
 AM
 Source
 Shape
 Depth
 AM frequency
 ASK
 Source
 Rate
 ASK amplitude
 FM
 Source
 Shape
 Deviation
 FM frequency
 FSK
 Source
 Rate
