GW Instek MFG-2000 Series User Manual

MODULATION
137
FM Frequency
The frequency of the modulation waveform (FM frequency) can be
set from 2mHz to 20kHz. For frequency modulation, the function
generator will accept internal or external sources.
Panel Operation
1. Press the MOD key.

2. Press F2 (FM).


3. Press F3 (FM Freq).
q

4. The FM Freq parameter will become
highlighted in waveform display panel.
5. Use the arrow keys and scroll
wheel or number pad to enter
the FM frequency.

/


 



6. Press F1~F3 to select the
frequency unit.
z

~
kz

Range
Modulation frequency
2mHz~20kHz
Default frequency
100Hz
