GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
120
Amplitude Modulation(AM)
An AM waveform is produced from a carrier waveform and a
modulating waveform. The amplitude of the modulated carrier
waveform depends on the amplitude of the modulating waveform.
The MFG-2000 function generator can set the carrier frequency,
amplitude and offset as well as internal or external modulation
sources.
Modulated Carrier
Waveform
Modulating
waveform
Selecting AM Modulation
Panel Operation
1. Press the MOD key.

2. Press F1 (AM).


