GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
286
Return Parameter
<NR3>
Returns the duty cycle as a
percentage.
Example
SOUR1:SQU:DCYC?
+9.90E+01
The duty cycle is set 99%.
SOURce[1|2|3|3RF]:RAMP:SYMMetry
Source Specific
Command
Description
Sets or queries the symmetry for ramp waves only.
The setting is remembered if the function mode is
changed. The default symmetry is 50%.
Note
For ramp waveforms, the Apply command and
AM/FM modulation modes ignore the current
symmetry settings.
Syntax
SOURce[1|2|3|3RF]:RAMP:SYMMetry {< percent>
|MINimum|MAXimum}
Example
SOUR1:RAMP:SYMM +5.00E+01
Sets the symmetry to the 50%.
Query Syntax
SOURce[1|2|3|3RF]:RAMP:SYMMetry?
{MINimum|MAXimum}
Return Parameter
<NR3>
Returns the symmetry as a
percentage.
Example
SOUR1:RAMP:SYMMetry?
+5.00E+01
Sets the symmetry to the 50%.
