MFG-2000 Series User Ma
nual
150
Pulse wave
1
μ
Hz~
25
MHz(max)
Ramp wave
1
μ
Hz~1MHz
Default frequency
1 kHz
PM Wave Shape
The function generator ca
n accept inter
nal or external s
ources. The
internal sources can includ
e sine, square,
triangle,
up ramp a
nd
down ramp. The def
ault wave shape is sine.
Panel
Operation
1.
S
elect the MOD key.
2.
Pre
ss F4 (PM).
3.
Pre
ss F4 (Shape)
.
ha
4.
Pre
ss F1~F5 to select a
waveform shape.
~
Da
5.
Pre
ss Return to return t
o the
previous menu.
Range
W
a
veform
Square wave
50% Duty Cycle
Up Ramp
100% Symmetry
T
riangle
50% Symmetry
Dn Ramp
0% Symmetry
149
