MFG-2000 Series User Manual
278
<amplitude>
1mV~2.5 (50Ω)
<offset>
±5 Vpk ac +dc (50Ω)
Example
SOUR1:APPL:PULS 1KHZ,MIN,MAX
Sets frequency to 1kHz and sets the amplitude to
minimum and the and offset to the maximum.
SOURce[1|2|3|3RF]:APPLy:NOISe
Source Specific
Command
Description
Outputs Gaussian noise with a 50 MHz
bandwidth. Amplitude and offset can also be set.
Note
Frequency cannot be used with the noise function;
however a value (or DEFault) must be specified.
The frequency is remembered for the next function
used.
Syntax
SOURce[1|2|3|3RF]:APPLy:NOISe
[<frequency|DEFault> [,<amplitude> [,<offset>] ]]
Parameter
<frequency>
Not applicable
<amplitude>
1mV~10V (50Ω)
<offset>
±5 Vpk ac +dc (50Ω)
Example
SOUR1:APPL:NOIS DEF, 3.0, 1.0
Sets the amplitude to 3 volts with an offset of 1
volt.
SOURce[1|2|3|3RF]:APPLy:USER
Source Specific
Command
Description
Outputs an arbitrary waveform from the selected
channel. The output is that specified from the
FUNC:USER command.
Note
Frequency and amplitude cannot be used with the
DC function; however a value (or DEFault) must
be specified. The values are remembered for the
next function used.
