GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
288
Using the Apply command automatically sets the
front panel output to on.
Syntax
OUTPut[1|2|3|3RF|pulse] {OFF|ON}
Example
OUTP1 ON
Turns the output on.
Query Syntax
OUTPut[1|2|3|3RF|pulse]?
Return Parameter
1
0
ON
OFF
Example
OUTP1?
1
The channel 1 output is currently on.
OUTPut[1|2|3|3RF|pulse]:LOAD
Source Specific
Command
Description
Sets or queries the output termination. Two
impedance settings can be chosen, DEFault (50Ω)
and INFinity (high impedance >10 kΩ).
The output termination is to be used as a reference
only. If the output termination is set 50Ω but the
actual load impedance is not 50Ω, then the
amplitude and offset will not be correct.
Note
If the amplitude has been set and the output
termination is changed from 50Ω to high
impedance, the amplitude will double. Changing
the output termination from high impedance to
50Ω will half the amplitude.
If the output termination is set to high impedance,
dBm units cannot be used. The units will default to
Vpp.
Syntax
OUTPut[1|2|3|3RF|pulse]:LOAD {DEFault|INFinity}
Example
OUTP1:LOAD DEF
Sets the output termination to 50Ω.
