GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
291
Example
SOURCEPULSE:PULS:WIDT?
+2.000000000000E-08
The pulse width is set to 20 nanoseconds.
SOURCEPULSE:PULSe:DCYCle
Source Specific
Command
Description
Sets or queries the pulse duty cycle.
Note
The duty cycle is restricted to the following
limitations:
Pulse Duty Cycle ≥ 100×Minimum Pulse Width ÷
Pulse Period
Pulse Duty Cycle < 100×(1-Minimum Pulse
Width÷Pulse Period)
Syntax
SOURCEPULSE:PULSe:DCYCle{<percent>|MINimum|
MAXimum}
Example
SOURCEPULSE:PULS:DCYC MAX
Sets the duty to the maximum allowed.
Query Syntax
SOURCEPULSE:PULSe:DCYCle?
[MINimum|MAXimum]
Return Parameter
<NR3>
0.01%~99.99%(limited by
the current frequency
setting)
Example
SOURCEPULSE:PULS:PULS:DCYC?
+1.0000E+01
The duty cycle is set to 10%
SOURCEPULSE:PULSe:TRANsition
:LEADing
Source Specific
Command
Description
Sets or queries the pulse leading edge time. The
default rise time is 10ns. The leading and trailing
edge time can be different.
Note
The leading edge time is limited by the pulse
