Default Settings
The Preset key is used to restore the default panel
settings.

Output Settings
Function
Sine Wave
Frequency
1kHz
Amplitude
3.000 Vpp
Offset
0.00V dc
Output units
Vpp
Output terminal
50Ω
Modulation
(AM/ASK/FM/FS
K/PM/PSK/SUM)
Carrier wave
1kHz sine wave
Modulation wave
100Hz sine wave
AM depth
ASK amplitude
ASK frequency
100%
500mVpp
10Hz
FM deviation
100Hz
FSK hop frequency
100Hz
FSK frequency
10Hz
PM phase deviation
PSK phase
PSK frequency
180˚
180˚
10Hz
SUM amplitude
50%
Modem status
Off
PWM Modulation
Carrier wave
1kHz Square wave
Modulation wave
20kHz sine wave
PWM duty cycle
50%
