REMOTE INTERFACE
315
Phase Shift Keying (PSK)Commands
PSK Overview
The following is an overview of the steps required to generate an
PSK modulated waveform.
Enable PSK
Modulation
Configure Carrier
Select PSK Source
Select PSK Phase
Set PSK Rate
1. Turn on FSK modulation using the
SOURce[3RF]: PSK:STAT ON command.
2. Use the APPLy command to select a carrier
waveform. Alternatively, the FREQ, AMPl, and
DCOffs commands can be used to create a
carrier waveform with a designated frequency,
amplitude and offset.
3. Select an internal or external modulation source
using the SOURce[3RF]:PSK:MOD:INT
command.
4. Set the hop frequency using the
SOURce[3RF]:PSK:PHASE command.
5. Use the SOURce[3RF]: PSK:INT:RATE
command to set the PSK rate. The PSK rate can
only be set for internal sources.
SOURce[3RF]:PSKey:STATe
Source Specific
Command
Description
Turns PSK Modulation on or off. By default PSK
modulation is off.
Note
Burst or sweep mode will be disabled if PSK
modulation is enabled. As only one modulation is
allowed at any one time, other modulation modes
will be disabled when PSK modulation is enabled.
Syntax
SOURce[3RF]:PSKey:STATe {OFF|ON}
