GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
326
Query Syntax
SOURce[1|2|3]:PWM:INTernal:FREQuency?
Return Parameter
<NR3>
Returns the frequency in
Hz.
Example
SOUR1:PWM:INT:FREQ? MAX
+2.0000E+04
Returns the modulating frequency. (20kHz)
SOURce[1|2|3]:PWM:DUTY
Source Specific
Command
Description
Sets or queries the duty cycle deviation. The default
duty cycle is 50%.
Note
The duty cycle is limited by period, edge time and
minimum pulse width.
The duty cycle deviation of an external source is
controlled using the ±5V MOD INPUT terminal on
the rear panel. A positive signal (>0~+5V) will
increase the deviation (up to the set duty cycle
deviation), whilst a negative voltage will reduce
the deviation.
Syntax
SOURce[1|2|3]:PWM:DUTY {< percent>|minimum
|maximum}
Parameter
<percent>
0%~100% (limited, see
above)
Example
SOUR1:PWM:DUTY +3.0000E+01
Sets the duty cycle to 30%.
Query Syntax
SOURce[1|2|3]:PWM:DUTY?
Return Parameter
<NR3>
Returns the deviation
in %.
Example
SOUR1:PWM:DUTY?
+3.0000E+01
The current duty cycle is 30%.
