GW Instek MFG-2000 Series User Manual

QUICK REFERENCE
29
How to use the Digital Inputs
Background
The MFG-2000 has three main types of digital
inputs: the number pad, arrow keys and scroll
wheel. The following instructions will show you
how to use the digital inputs to edit parameters.
1. To select a menu item, press the corresponding
function keys below (F1~F6). For example the
function key F1 corresponds to the Soft key
“Sine”.
2. To edit a digital value, use the arrow keys to
move the cursor to the digit that needs to be
edited.
3. Use the scroll wheel to edit the parameter.
Clockwise increases the value, counter
clockwise decreases the value.
4. Alternatively, the number
pad can be used to set the
value of a highlighted
parameter.
