GW Instek MFG-2000 Series User Manual

MODULATION
151
PM Frequency
The frequency of the modulation waveform (PM Frequency) can be
set from 2mHz to 20kHz. The function generator can accept internal
or external sources.
Panel Operation
1. Press the MOD key.

2. Press F4 (PM).


3. Press F3 (PM Freq).
q

4. The PM Freq parameter will become
highlighted in the Waveform Display area.
5. Use the arrow keys and scroll
wheel or number pad to enter
the PM frequency.

/


 



6. Press F1~F3 to select the
frequency unit range.
z

~
kz

Range
Modulation frequency
2mHz~20kHz
Default frequency
100Hz
