OUTPut[1|2]:TRIGger:SLOPe
Source Specific
Command
Description
Configures the trigger output signal (TTL) as a
positive or negative slope. A positive slope will
output a pulse with a rising edge and a negative
slope will output a pulse with a falling edge.
Note
The Trig out signal depends on the selected trigger
source.
Trigger Source
Description
Immediate
A square wave is output from the Trig
out terminal with a 50% duty cycle at
the start of every sweep.
External
Trigger Output is disconnected.
Manual
A pulse (>1 us) is output from the
Trig out terminal at the start of each
sweep.
Syntax
OUTPut[1|2]:TRIGger:SLOPe {POSitive|NEGative}
Example
OUTP1:TRIG:SLOP NEG
Sets the Trig out signal as negative edge.
Query Syntax
OUTPut[1|2]:TRIGger:SLOPe?
Return Parameter
POS
Positive edge
NEG
Negative edge
Example
OUTP1:TRIG:SLOP?
NEG
The Trig out signal is set to negative edge.
OUTPut[1|2]:TRIGger
Source Specific
Command
Description
Turns the trigger out signal on or off from the Trig
out terminal on the rear panel. When set to on, a
trigger signal (TTL) is output at the start of each
pulse. The default is setting is off.
Syntax
OUTPut[1|2]:TRIGger {OFF|ON}
