REMOTE INTERFACE
325
The PWM source is set to internal.
SOURce[1|2|3]:PWM:INTernal:FUNction
Source Specific
Command
Description
Sets the shape of the modulating waveform from
sine, square, triangle, upramp and dnramp. The
default shape is sine.
Note
Square and triangle waveforms have a 50% duty
cycle. Upramp and dnramp have a symmetry to
100% and 0%, respectively.
Carrier must be a pulse or PWM waveform.
Syntax
SOURce[1|2|3]:PWM:INTernal:FUNction
{SINusoid|SQUare|TRIangle|UPRamp|DNRamp}
Example
SOUR1:PWM:INT:FUN SIN
Sets the PWM modulating wave shape to sine.
Query Syntax
SOURce[1|2|3]:PWM:INTernal:FUNction?
Return Parameter
SIN
Sine
UPRAMP
Upramp
SQU
Square
DNRAMP
Dnramp
TRI
Triangle
Example
SOUR1:PWM:INT:FUNC?
SIN
The shape for the modulating waveform is Sine.
SOURce[1|2|3]:PWM:INTernal:FREQuency
Source Specific
Command
Description
Sets the modulating waveform frequency for
internal sources. The default frequency is set to
10Hz.
Syntax
SOURce[1|2|3]:PWM:INTernal:FREQuency
{<frequency>|MINimum|MAXimum}
Parameter
<frequency>
2 mHz~ 20 kHz
Example
SOUR1:PWM:INT:FREQ MAX
Sets the frequency to the maximum value.
