GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
180
Marker Frequency
The marker frequency is the frequency at which the marker signal
goes low (The marker signal is high at the start of each sweep). The
marker signal is output from the TRIG output terminal on the rear
panel. The default is 550 Hz.
Panel Operation
1. Press the SWEEP key.

2. Press F6 (More).


3. Press F3 (Marker)
ak

4. Press F2 (ON/OFF) to toggle
the marker on or off.
OO

5. Press F1 (Freq) to select the
marker frequency.
q

6. The Marker parameter will become highlighted
in the parameter window.
