HEIDENHAIN iTNC 530 HSCI Service Manual

February 2012 4 – 21
4 Error messages
4.1 Introduction
The iTNC 530 features a comprehensive integral monitoring system for the prevention of input
or operation errors, as well as for identification and diagnosis of technical defects on the control
and the connected devices. The monitoring system is an integral component of the iTNC hardware
and software and is active as long as the control is switched on. The presence of a technical fault
or an operation error is made known through a plain-language message.
Moreover, the machine manufacturer can define specific PLC error messages.
Type of
error message
PLC error messages
 Machine-specific error messages
 Are defined by the machine manufacturer (e.g., coolant pump defective, protective door
open)
 The machine manufacturer defines how the control reacts to a PLC error message (NC Stop,
EMERGENCY STOP, etc.)
 The machine manufacturer defines whether the control can still be operated or has to be rebooted
after a PLC error message.
 If you have any questions, please contact your machine manufacturer.
NC error messages
 Are part of the HEIDENHAIN NC software.
 Can be subdivided into error messages that result from operation, programming and machine
applications and those that indicate a technical defect (devices, electronic and mechanical
components, etc.)
 HEIDENHAIN defines how the control reacts to an NC error message (NC Stop, EMERGENCY
STOP, etc.)
 HEIDENHAIN defines whether the control can still be operated or has to be rebooted after
an NC error message.
 If you have any questions, please contact your machine manufacturer and/or HEIDENHAIN.
Is the displayed error message an NC or PLC error message?
Call the ERR window or the log to answer this question:
Operating-system error messages
 Often contain the note CHILD PROCESS ERROR.
 The control cannot be operated any more and has to be rebooted.
 If you have any questions, please contact your machine manufacturer and/or HEIDENHAIN.
Display PLC error message NC error message
ERR window
In the Group column.
Call --> See ”ERR key” on page 4 – 25.
PLC GENERAL
or
OPERATION
or
PROGRAMMING
Log
In lines that start with the entry ERR.
Call --> See ”Log” on page 8 – 79.
P
(number and text of
error message)
N
(number and text of
error message)
Note
No error numbers are assigned to NC error messages that begin with N-1.
