31.4.7 Integrated PLC
MP Function and input Software
version and
behavior
MP4000.0-63 Options for the conditional compilation of the PLC program
MP4020 PLC functions
Format: %xxxxxxxxxxxxxx
Input: Bit 0 to bit 4: Reserved
Bit 5: Single or double spindle operation
0: Single-spindle operation
1: Double-spindle operation
Bit 6 – Reserved
Bit 7 – Reserved
Bit 8 – Behavior after an ext. emergency stop
0: "Approach position" is not automatically activated
1: "Approach position" is automatically activated
Bit 9 – Behavior of a simulated key
0: Simulated key is transferred immediately to the NC
1: Simulated key is processed first by an active PLC window before
being transferred to the NC
Bit 10 – Behavior of a locked key
0: Locked key only works on the active PLC window
1: Locked key works on neither the active PLC window nor on the NC
Bit 11 – PLC counter in MP4120.x
0: Input in PLC cycles
1: Input in seconds
Bit 12 – Font size in PLC window
0: Automatic adaptation of font size to screen
1: Font size for BF 120
Bit 13 – Reserved, set to 0
Bit 14 – PLC module interface for 18 axes
0: PLC module interface for 14 axes plus spindle (axes = bit 0 to bit 14,
spindle = bit 15).
1: PLC module interface for 18 axes plus spindle (axes = bit 0 to bit 17,
spindle = bit 31).
Bit 15 – Saving the changes to tables to memory medium
0: Cyclic saving of tables (behavior same as up to and including 606 42x-
01 SP 04)
1: Save tables each time they are closed
Bit 16 – Time at which strobe markers are reset
0: Do not reset strobe markers until the action triggered by
acknowledgment of the strobe is concluded by the NC
1: Reset strobe markers immediately upon acknowledgment (behavior
same as up to and including 606 42x-01 SP 04)
RESET
MP4030.x Assignment of physical/logic PL (not required for HSCI systems)
MP4031 Monitoring of number of PLs (not required for HSCI systems)
MP4040 Set PLC output after shutdown PLC
RUN
MP4041 Time after shutdown until setting of the PLC output from MP4044
Input: 0 to 1000 [s]
PLC
RUN
MP4043 Delay during shutdown for the PLC to execute final actions
Input: 1 to 60 [s]
0: No delay
PLC
RUN
MP4044 PLC output to be set after shutdown
Input: Symbolic name of PLC output
0: Cannot be evaluated, results in an error message
PLC
RUN
MP4045 Reserved
MP4050.0-8 Traverse distance for lubrication of axes 1 to 18
Input: 0 to 99 999.999 [m or 1000°]
PLC
RUN
